FGS Heritage 47 Slim Hinged Doors & French Doors

FGS Heritage 47 Slim Door System

FGS Heritage 47 window and door system, provides the ideal solution for applications such as listed building renovations and large scale replica-refurbishment projects where planning constraints are to be considered. This slim aluminium frame system is designed to be built as a series of horizontal modules which can be stacked using horizontal couplers to form a multi-part window/ door featuring a specially design drip bar between modules.

Heritage profiles utilise innovative polyamide thermal break technology which creates a barrier between the cold air outside and the warm air inside. This technology significantly reduces thermal transmittance and enhances the overall U Value of a product and is designed to meet the exacting requirements of Document L 2010.

FGS Heritage 47 products are available in a choice of standard or non-standard colours, including metallic, dual colour, textured, and anodised effect powder coated finishes. Prices and lead times vary if a non-standard paint is used.

Alitherm Heritage Door: Design Limitation and Performance:

• Single or double doors
• Add window modules above and to the side of the doors if needed
• Slim sightlines
• Multi point locking and face mounted shoot bolts
• Polyamide thermal break provides enhanced thermal performance
• Heritage and Art Deco hardware options

Maximum sizes: Max Width: 900mm Max Height: 2100mm Glass as a standard will be 28mm double glazed toughened, low e, Argon Filled cavities with a black warm edge spacer bar giving you a U-value of around 1.6 W/m²K. We could upgrade the glass to solar glass, laminated glass etc. Integral blinds is also an option. Ask a member of the Fusion Sales Team for prices/ information.
