Schüco ADS Door System

The Schüco ADS (Aluminium Door System) door range, offers contemporary, high performance and robust aluminium swing doors.

This German designed aluminium hinged door brand, is in terms of reputation and proven performance, the best commercial and residential door system in the world. (Schüco is sometimes spelt Schueco)

 Fusion Glazing Systems is a Schüco manufacturing partner, as well as an installations partner. We manufacture Schüco products under licence in our factory in Uxbridge.

We offer Schüco ADS 65 as well as ADS 70 HI. Both these systems are suitable for economical commercial and high end residential entrance solutions, in conjunction with very good thermal insulation.

Optional fittings also allow it to be used as a multi-purpose door and integrated in the building security and building management system. In conjunction with the Schueco façade and window systems, the modern door design gives the developer numerous design options for the building envelope.

The modern entrance solution for efficient building envelopes that require thermal insulation.

Schuco ADS 65 Door System
Min max sizes:

Single Door Max Width (mm): 1500mm (1500mm wide x 2400mm (max height))
Single Door Max Height (mm): 3000mm (1200mm wide (max width) x 3000mm H)
Opening width (double-leaf): Up to 2,800 mm
Max. leaf weight: 200 kg
Frame Depth (mm): 65mm

Performance:

Burglar resistance: DIN V ENV 1627 to 1630 up to WK3

Features:
• Optimised for front and side entrance doors.
• Outstanding thermal insulation with basic depth 65 mm.
• Good thermal insulation due to wide insulation zone.
• Design series: ADS 65 SL (Soft Line), ADS 65 RL (Residential Line).
• Comprehensive range of opening types, single and double-leaf inwards and outwards-opening doors, emergency doors, anti-finger-trap doors, swing doors.
• Optional low threshold for easy access to building if needed
• Barrel hinge, infinitely adjustable in three dimensions.
• Burglar resistance DIN V ENV 1627 to 1630 up to WK3.
• Intrusion safety class up to RC3
• Heavy duty, soft line and residential line options available.

About us

Fusion Glazing Systems specialises in a wide range of Aluminium slim sliding doors, architectural glazing, aluminium windows, glazed hinged doors, French double doors, aluminium bifold doors, roof lights, walk on glass floors, glass balustrade systems, curtainwall and bespoke structural frameless glazing.

We are experts in designing, manufacturing, supplying and installing, high-performance, beautiful and easy to use, aluminium minimal sliding doors, aluminium windows and other architectural glazing, and frameless glazing systems.

Fusion Glazing Systems has been established since 1968. Fusion focuses on the residential side of the industry as well as tackling the larger commercial projects. We have a trusted reputation, built over decades of committed work with returning clients, contractors and architects.

Our clients own homes around London, Buckinghamshire, Berkshire, Middlesex, Sussex, Herefordshire, Surrey, Oxfordshire and Bedfordshire. We cover the South East of England.

We manufacture our windows, doors and Curtain Wall at our factory in Hemel Hempstead.

We also have a showroom where you can come and see and feel the systems we offer first hand.

We run our showroom on an appointment basis.



Fusion Glazing Systems offers a comprehensive service:

• helping our clients with expert design advice from the inception of a project
• we execute a thorough site survey to measure up the project once openings are formed
• we issue architectural drawings showing what we measured and what is agreed
• we fabricate your windows/doors in our Hemel Hempstead factory.
• we install your windows/doors with our trained and experienced, in-house installation teams, to a promised lead time, efficiently.
