Schüco Bifold/ Sliding Folding Doors

Schüco ASS 70 FD Bifold Door System

Schüco is a German brand of high performance, slim, aluminium bifold doors. Fusion Glazing Systems manufactures this system under Schüco licence, in our factory in Uxbridge, West London.

This system offers clever design, outstanding engineering and robust build quality. Schüco has a reputation of being built to last.

This aluminium bi-fold door system also has one of the slimmest sightlines, with just 120mm frame width (60mm per frame) between two panes of glass. This lets you maximise your light coming into the living space and minimise framing. A flush floor threshold is available.

The Schüco bi-fold is the only bi-fold door that can be up to 3m tall without any modification. The high standard of engineering means its rollers can carry 100kg per panel. The door leaf stack folds easily, with minimal force, inward or outward, and slides to the right and/or to the left. The door leaves roll almost silently on high-quality roller carriers and are securely guided at the top and at the bottom.

We most regularly install Schüco bi-fold doors into residential properties. But it is actually a robust commercial system. The doors are designed to be opened and closed frequently and tend to be installed in places with high volumes of traffic. For this reason, they are often found in commercial settings, such as bars, hotels and restaurants.

The system is very versatile and offers plenty of configuration and colour choices to suit any setting. In a residential property, the door will add value, be a great investment and last for many years to come.

Schüco ASS 70 FD Bifold Door System is a high-performance system, and very secure. It has a six-point high security locking system. It will also be equipped with anti-lift locking barrels and anti-burglar hinges.

Key benefits:

• Robust, thermally insulated aluminium profiles
• Easy-to-operate (lockable) one-hand handles
• Smooth quiet sliding
• Various configurations including slide away corners
• A higher level of sound reduction can be selected
• Can be double or triple glazed (max weight 100kg per panel)

Min max sizes:
Slide Folding Door Max Width (mm): 1200mm (per sash)
Slide Folding Door Max Height (mm): 3000mm (per sash)
Slide Folding Door Max Weight (kg): 100kg
Glazing (mm): 6-45mm
Overall Side Profile: 131mm
Vent Profile: 54mm
Panel Junction Profile: 120mm
Frame Depth: 70mm
Air Permeability: Class 2 in accordance with EN 12207
Water Resistance: Class 9A in accordance with EN 12208
Resistance to Wind: Load Class C3 in accordance with EN 12210
Security: PAS:24 Enhanced Security Performance Requirements for Doors and Windows in the UK.
Thermal Performance: Uw value of 1.6 W/m2K (using glass units of 1.0 W/m2K)
