Smart Visofold Bifold/ Sliding Folding Doors

Smart Visofold 1000 Bifold Door System

The Smart Visofold 1000 bifold door system, creates an impressive opening, a flush internal to external area, bringing lots of light into your open living space. Suitable for both domestic and commercial projects.

All Visofold profiles feature a polyamide thermal break that enhances the thermal performance of the profile and improves the overall U-Value. Profiles feature EPDM high quality gaskets and weather brushes to aid weather resistance. Visofold complies with the requirements of Building Regulations Document L 2010. Security is assured by multi-point lock mechanisms on main opening sashes, and shoot-bolt locking on floating mullions.

KEY BENEFITS
 • Attractive, slim-line profiles offer reduced sightlines
 • Choice of opening configurations to suit any application
 • Profiles available in either square or rounded edge options
 • Fabricated using mitred corners
 • U values as low as 1.5W/m²K using 1.0 W/m²K centre pane
 • Can be upgraded to PAS 24 to make it Document Q compliant

DIMENSIONS
• Slide Folding Sash Max Width 1200mm (per sash)
• Slide Folding Sash Max Height 2500mm (per sash)
• Slide Folding Sash Max Weight 100kg
• Glazing 24mm, 28mm, 32mm, 34mm, 36mm double or triple glazed units
• Frame Depth 70mm
• Typical Sightlines 132mm OPTIONS
• Available in standard or non-standard RAL colours or textured finishes
• Dual colour available as an upgrade
• Choose to fold the sashes internally or externally
• Option of either low thresholds for unimpeded, easy access, or rebated fully weathered thresholds
• Lock mechanism available with domestic style ‘lift-up’ handle and an adjustable, one-piece keep.
Handles can be chrome, satin silver, black or white
